LR Elbow (Long Radius Elbow) Manufacturer
Buttweld Long Radius Elbows Fittings Supplier, ASTM A403 SS 180 Deg LR Elbows, Long Radius Elbows Dimensions, Alloy Steel 180 Deg. LR Elbow, Nickel Alloy 200 Long Radius Elbow, Monel 90 Deg. Buttweld LR Elbow, 304 SS Long Radius Elbows, High Quality LR Elbow Manufacturer Of in Mumbai, India.
Buttweld Long Radius Elbow Manufacturer, Global Supplier of ANSI B16.9 LR Elbows Fittings, Butt Weld Long Radius 90 Degree Elbows, Stockist of Stainless Steel Long Radius Elbow, 3D Long Radius Elbows Dealer in India, ASME B16.9 5D Long Radius Elbow, Schedule 10 180 Deg. LR Elbow.
Shankh Metals And Alloys Is An ISO: 9001:2008 Certified Company. We Are Manufacturer, Stockholder and Exporter of Long Radius Elbow. We are proactive organization Specialist in Stainless Steel Long Radius Pipe Elbow and Other Quality Products that meet and exceed customer`s specific requirements and thus ensure complete satisfaction. We are capable of providing a vast range of materials like Stainless Steel 90 Degree LR Pipe Elbows, Carbon Steel Buttweld 90° Pipe Elbows & Alloy Steel Buttweld 90° long Radius Pipe Elbows Pipe Fittings from stock, to suit your needs. We have great pleasure to introduce ourselves as one of the leading Stockists & Suppliers of Stainless Steel ASME B16.9 Long Radius Elbow,Copper Nickel 180 Deg Elbow Exporter, Hastelloy C22 180 Deg. Pipe Elbow and Other Range of Pipe Fittings.
Stockholder Of Long Radius Elbows, Steel LR Pipe Elbow Wholesaler, Best Price of Duplex Steel LR Pipe Elbow, Hastelloy C22 Long Radius Elbows, Copper Nickel LR Elbow Exporter, Inconel Buttweld Long Radius Elbow, 1 inch Buttweld Pipe Elbow, Alloy 20 45° LR Elbow Traders in India.
Table Of Content
- Best Offer On Elbow
- Standard Specification For Buttweld Long Radius Pipe Elbow
- Material & Grades of Buttweld Long Radius Pipe Elbow
- ASME B16.9 Buttweld Long Radius Elbow Available Types
- Buttweld Long Radius Elbow Dimension
- Buttweld Long Radius Elbow Application
- Export Destinations For Long Radius Buttweld Pipe Elbow
- Price List Of Elbows
- Long Radius Elbows Weight Chart
Long Radius Elbow Manufacturer & Supplier In Mumbai
Nom.
Pipe
Size |
Pipe
Sched.
or No. |
Center-
to-Center
Dimen. |
Back-
to-
Face |
Outside
Dia. |
Inside
Dia. |
Wall
Thick. |
Approx.
Weight
(lb.) |
| H | J | OD | ID | T | |||
| STANDARD WEIGHT | |||||||
| 1/2 | 40 | 3 | 1 7/8 | 0.840 | 0.622 | 0.109 | 0.3 |
| 3/4 | 40 | 2 1/2 | 1 11/16 | 1.050 | 0.824 | 0.113 | 0.3 |
| 1 | 40 | 3 | 2 3/16 | 1.315 | 1.049 | 0.133 | 0.7 |
| 1 1/4 | 40 | 3 3/4 | 2 3/4 | 1.660 | 1.380 | 0.140 | 1 |
| 1 1/2 | 40 | 4 1/2 | 3 1/4 | 1.900 | 1.610 | 0.145 | 1.5 |
| 2 | 40 | 6 | 4 3/16 | 2.375 | 2.067 | 0.154 | 3 |
| 2 1/2 | 40 | 7 1/2 | 5 3/16 | 2.875 | 2.469 | 0.203 | 6 |
| 3 | 40 | 9 | 6 1/4 | 3.500 | 3.068 | 0.216 | 9 |
| 3 1/2 | 40 | 10 1/2 | 7 1/4 | 4.000 | 3.548 | 0.226 | 12 |
| 4 | 40 | 12 | 8 1/4 | 4.500 | 4.026 | 0.237 | 17 |
| 5 | 40 | 15 | 10 5/16 | 5.563 | 5.047 | 0.258 | 28 |
| 6 | 40 | 18 | 12 5/16 | 6.625 | 6.065 | 0.280 | 46 |
| 8 | 40 | 24 | 16 5/16 | 8.625 | 7.981 | 0.322 | 90 |
| 10 | 40 | 30 | 20 3/8 | 10.750 | 10.020 | 0.365 | 156 |
| 12 | - | 36 | 24 3/8 | 12.750 | 12.000 | 0.375 | 236 |
| 14 | 30 | 42 | 28 | 14.000 | 13.250 | 0.375 | 294 |
| 16 | 30 | 48 | 32 | 16.000 | 15.250 | 0.375 | 404 |
| 18 | - | 54 | 36 | 18.000 | 17.250 | 0.375 | 512 |
| 20 | 20 | 60 | 40 | 20.000 | 19.250 | 0.375 | 617 |
| 24 | 20 | 72 | 48 | 24.000 | 23.250 | 0.375 | 886 |
| EXTRA STRONG | |||||||
| 1/2 | 80 | 3 | 1 7/8 | 0.840 | 0.546 | 0.147 | 0.5 |
| 3/4 | 80 | 2 1/2 | 1 11/16 | 1.050 | 0.742 | 0.154 | 0.5 |
| 1 | 80 | 3 | 2 3/16 | 1.315 | 0.957 | 0.179 | 1 |
| 1 1/4 | 80 | 3 3/4 | 2 3/4 | 1.660 | 1.278 | 0.191 | 1.5 |
| 1 1/2 | 80 | 4 1/2 | 3 1/4 | 1.900 | 1.500 | 0.200 | 2 |
| 2 | 80 | 6 | 4 3/16 | 2.375 | 1.939 | 0.218 | 4 |
| 2 1/2 | 80 | 7 1/2 | 5 3/16 | 2.875 | 2.323 | 0.276 | 7.5 |
| 3 | 80 | 9 | 6 1/4 | 3.500 | 2.900 | 0.300 | 12 |
| 3 1/2 | 80 | 10 1/2 | 7 1/4 | 4.000 | 3.364 | 0.318 | 17 |
| 4 | 80 | 12 | 8 1/4 | 4.500 | 3.826 | 0.337 | 23 |
| 5 | 80 | 15 | 10 5/16 | 5.563 | 4.813 | 0.375 | 40 |
| 6 | 80 | 18 | 12 5/16 | 6.625 | 5.761 | 0.432 | 67 |
| 8 | 80 | 24 | 16 5/16 | 8.625 | 7.625 | 0.500 | 138 |
| 10 | 60 | 30 | 20 3/8 | 10.750 | 9.750 | 0.500 | 215 |
| 12 | - | 36 | 24 3/8 | 12.750 | 11.750 | 0.500 | 300 |
| 14 | - | 42 | 28 | 14.000 | 13.000 | 0.500 | 376 |
| 16 | 40 | 48 | 32 | 16.000 | 15.000 | 0.500 | 524 |
| 18 | - | 54 | 36 | 18.000 | 17.000 | 0.500 | 676 |
| 20 | 30 | 60 | 40 | 20.000 | 19.000 | 0.500 | 824 |
| 24 | - | 72 | 48 | 24.000 | 20.000 | 0.500 | 1183 |
Standard Specification For Buttweld Long Radius Pipe Elbow
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Elbow ( 1/2″～24″), ERW / Welded / Fabricated Elbow (1/2″～48″)
Type : Seamless / ERW / Welded / Fabricated
Thickness : Schedule 5S, 10S, 20S, S10, S20, S30, STD, 40S, S40, S60, XS, 80S, S80, S100, S120, S140, S160, XXS and etc.
Form : 90 Deg Long Radius Elbow, 45 Deg Long Radius Elbow, 180 Deg Long Radius Elbow, 1D Elbow, 3D Elbow, 5D Elbow.
Material & Grades of Buttweld Long Radius Elbow :
Stainless Steel Buttweld LR Elbow (Long Radius Elbow) :
ASTM A403 WP316/316L, ASTM A403 SA / A 774 WP-S, WP-W, WP-WX 304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404
Duplex & Super Duplex Steel Buttweld LR Elbow (Long Radius Elbow) :
ASTM A 815, ASME SA 815 UNS NO S31803, S32205. UNS S32750, S32950. Werkstoff No. 1.4462
Carbon Steel Buttweld LR Elbow (Long Radius Elbow) :
ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low Temperature Carbon Steel LR Elbow (Long Radius Elbow) : ASTM A420 WPL3, A420 WPL6
Alloy Steel Buttweld LR Elbow (Long Radius Elbow) :
ASTM / ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Nickel Alloy Buttweld LR Elbow (Long Radius Elbow) :
ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
ASME B16.9 Buttweld LR Pipe Elbow Available Types
| Buttweld Long Radius Elbow | Butt Weld Long Radius 180 Degree Elbows |
| Steel Long Radius Elbow | 90° Long Radius Elbow |
| ASME B16.9 180 deg Long Radius Elbow | Schedule 10 45Degree LR Elbow |
| Stainless Steel 180 Degree LR Elbow Suppliers | SS Long Radius Elbows |
| ANSI B16.9 45 Degree Buttweld Elbow Dealer | ASME B16.28 Buttweld 180 Degree Elbow Exporter |
| Welded 3D LR Elbow Stockholder | Seamless 90° Pipe Elbow Distributors |
| Carbon Steel 5D LR Elbow | High Quality LR Elbow Manufacturer |
| ASTM A403 Stainless Steel Long Radius Elbows | Duplex Steel 1D Pipe LR Elbow |
| Super Duplex Steel 45 Deg Elbow | Copper Nickel 90 Deg Long Radius Elbow |
| High Nickel Alloy Long Radius Elbow | Hastelloy 90° Long Radius Pipe Elbow Stockist |
| Titanium 180 Degree LR Pipe Elbow | Inconel Butt weld 180 Deg LR Pipe Elbow |
Application of Stainless Steel Buttweld Fittings
- Industrial Boilers
- Power Plants
- Nuclear Plants
- Oil & Gas Industry
- Refineries
- Ship Building
- Heat Exchangers
- Condensers
- Paper & Pulp
- Marine Applications
- Nuclear Power
- Fossil Fuel Power Plants
Price List Of Elbows
90 long radius elbow
FOB Price: US $0.5-6 / Piece
short radius sch40 180 Degree elbows
FOB Price: US $1.2-2500 / Piece
45 D LONG RADIUS ELBOW
FOB Price: US $1-5000 / Piece
45 short radius elbow
FOB Price: US $0.11-999 / Piece
Pipe Fittings 180 degree long radius elbow
FOB Price: US $0.2-50 / Piece
180 short radius elbow
FOB Price: US $0.2-500 / Piece
1d elbow
FOB Price: US $1.2-2500 / Piece
1.5D Elbow
FOB Price: US $0.1-650 / Piece
180 Degree 3d elbow
FOB Price: US $0.11-1 / Piece
5d radius elbows
FOB Price: US $1-1000 / Piece
stainless steel Elbow 45,90,180 LR/SR
FOB Price: US $500-1000 / Ton
steel butt welding pipe elbow
FOB Price: US $8-8000 / Piece
180 Buttweld Return Bend
FOB Price: US $500-600 / Piece
butt-welding straight tees and crosses
FOB Price: US $1-100 / Piece
Reducing Outlet Tees/Unequal Tees
FOB Price: US $1-99 / Piece
Equal Tee
FOB Price: US $0.5-500 / Piece
Reducing Tee
FOB Price: US $0.25-6.25 / Piece
Stainless steel equal cross
FOB Price: US $1000-2000 / Ton
Reducing Cross
FOB Price: US $1-5000 / Piece
Reducer stainless steel pipe fittings ANSI B16.9
FOB Price: US $1-1000 / Piece
asme b16.9 concentric reducer
FOB Price: US $10-1000 / Piece
asme b16.9 eccentric reducer sch40
FOB Price: US $1-10000 / Ton
Stub End stainless steel pipe fittings ANSI ASME B16.9
FOB Price: US $1-1000 / Piece
Lap Joint Stub End(wp304,wp304l,wp316,wp316l,wp316ti,wp317l,wp321,wp347)
FOB Price: US $1-1000 / Piece
seamless stainless steel pipe long Stub End
FOB Price: US $0.1-9.9 / Piece
Stainless Steel Short Stubend
FOB Price: US $5-100 / Kilogram
ASME B16.9 Pipe Cap
FOB Price: US $1-1000 / Ton
Carbon steel cap/Forged Pipe fittings/butt welded end cap
FOB Price: US $0.1-10 / Piece
collar pipe fittings
FOB Price: US $0.8-4 / Piece
Swedge Nipple
FOB Price: US $1-30 / Piece
Pipe Nipples
FOB Price: US $0.1-100 / Piece
Barrel Nipple
FOB Price: US $1-999999 / Piece
Reducing Nipple
FOB Price: US $1-1200 / Piece
3D 5D 7D 9D Carbon Steel Pipe Fitting Butt Weld Bend
FOB Price: US $1.01-668.8 / Piece
carbon Steel Long Radius Bend in pipe fittings
FOB Price: US $1-1000 / Piece
Piggable Bend
FOB Price: US $0.5-10000 / Piece
pipe fittings laterals
FOB Price: US $0.5-89 / Piece
