ASTM A234 Alloy Steel WP5 Pipe Bends Supplier
Alloy Steel WP5 Pipe Bends Supplier, Alloy Steel ASTM A234 WP5 Seamless Pipe Bend, WP5 Alloy Steel Welded Pipe Bend, A234 WP5 Alloy Steel High Pressure Bending, Chrome Moly Alloy Steel WP5 U Pipe Bend, Manufacturer Of ASTM A234 WP5 Alloy Steel J Pipe Bend, ANSI B16.9 Alloy WP5 3D Pipe Bends in Mumbai, India.
Alloy Steel WP5 Pipe Bends, Alloy Steel A234 WP5 Buttweld Bend, Stockist of Alloy Steel WP5 Long Radius Bend, Alloy Steel WP5 Piggable Bend Dealer in India, Global Supplier of Alloy Steel WP5 Hot Induction Bend, ANSI B16.9, ANSI B16.28, MSS SP-43, or MSS SP-75 WP5 Pipe Bends.
Shankh Metals And Alloys Is An ISO: 9001:2008 Certified Company.We Manufacturer Our Products By High Grade Material To Provide Good Quality Alloy Steel WP5 Pipe Bends To Our Domestic And Overseas Customers. Bends accomplish a Lot of admiration by our clients owing to its high strength, dimensional correctness, high tension power, corrosion resistant and consistency products like Alloy Steel WP5 3D Pipe Bend, Alloy Steel WP5 Hot Induction Bends & Alloy Steel WP5 ASTM A234 Pigabble Bends. These products are used in various commercial, industrial and automobile industries. We manufacture ANSI B16.9 Welded Pipe Bend using high grade of raw material by implementing most ultra modern technology. These products are clients can avail from us at various sizes, shapes and design as per the requirements.We are one of the top Manufacturers and Suppliers of ASTM A234 Alloy Steel WP5 Seamless Pipe Bends. We Manufacture Other range of ASTM A234 Alloy Steel WP5 Pipe Bends such as A234 Alloy Steel WP5 Long Radius Bend, Alloy Steel WP5 Piggable Bend, A234 Hot Induction Bend, A234 X42 Alloy Steel WP5 Seamless Pipe Bend, A234 Welded Pipe Bend, Alloy Steel WP5 X46 U Pipe Bend, Alloy Steel X52 WP5 J Pipe Bend, A234 X56 Mitered Pipe Bend, Alloy Steel X65 WP5 3D Pipe Bend in Mumbai, India.
Best Price of WP5 Alloy Steel Mitered Pipe Bend Exporter, 5Cr-1/2Mo Alloy Steel Pipe Bend, A234 Alloy Steel WP5 5D Pipe Bend, Stockholder Of Alloy Steel WP5 10D Pipe Bend, ASME SA234M Alloy WP5 Customized Pipe Bend Wholesaler, A234 WP5 45 Degree Pipe Bend Traders in India.
Table Of Content
- Standard Specification For Alloy Steel WP5 Pipe Bend
- Manufacturing Standards Of Alloy Steel WP5 Pipe Bends
- Types Of Alloy Steel WP5 Pipe Bends
- ASTM A234 Alloy Steel WP5 Long Radius Bend
- ASTM A234 Alloy Steel WP5 Piggable Bend
- ASTM A234 Alloy Steel WP5 Hot Induction Bend
- ASTM A234 Alloy Steel WP5 Seamless Pipe Bend
- ASTM A234 Alloy Steel WP5 Welded Pipe Bend
- ASTM A234 Alloy Steel WP5 U Pipe Bend
- ASTM A234 Alloy Steel WP5 J Pipe Bend
- ASTM A234 Alloy Steel WP5 Mitered Pipe Bend
- ASTM A234 Alloy Steel WP5 3D Pipe Bend
- ASTM A234 Alloy Steel WP5 5D Pipe Bend
- ASTM A234 Alloy Steel WP5 10D Pipe Bend
- Chemical Composition of Grade Alloy Steel WP5 Pipe Bends
- Mechanical Properties of Alloy Steel WP5 Pipe Bends
- Price List Of Alloy Steel WP5 Pipe Bend
- Alloy Steel WP5 Pipe Bend Available Types
- Alloy Steel WP5 Pipe Bend Application
- Export Destinations For Alloy Steel WP5 Pipe Bend
Standard Specification Of Alloy Steel WP5 Pipe Bend
Specifications : ASTM A234 & ASME SA234
Dimensions : ASME/ANSI B16.9 / B16.28 and MSS SP-43 / SP-75
Size : Seamless Pipe Bends (1/2″ – 24″), ERW / Welded / Fabricated Pipe Bends (2″ – 36″)
Outer Diameter : 38.0 mm – 206.0 mm
Wall Thickness : 1.5 mm / 2.0 mm / 3.0 mm – greater wall thickness at request
Bend Radii : 75 / 100 / 150 / 250 / 300 / 500 / 800 / 1,000 / 1,200 / 1,500 mm
Bending Radius(R): R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Bending angle (θ): 15°, 30°, 45°, 60°, 90°, 135°, 180°
Manufacturing Standards Of Alloy Steel WP5 Pipe Bends :
| ASME Pipe Bend | ANSI B16.9, ANSI B16.28, MSS-SP-43 |
| DIN Pipe Bend | DIN2605, DIN2615, DIN2616, DIN2617, DIN28011 |
| EN Pipe Bend | EN10253-1, EN10253-2 |
| ASTM A234 | ASME SA234 – Standard Specification for Wrought Austenitic Alloy Steel WP5 Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Fittings Buttwelding |
| ASME B16.25 | Buttwelding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Buttwelding Returns |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
Types Of Grade Alloy Steel WP5 Pipe Bends
Chemical Composition of Grade WP5 Alloy Steel Pipe Bends
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A234 WP5 | ≤0.15 | ≤0.6 | ≤0.5 | ≤0.04 | ≤0.03 | 4-6 | 0.44-0.65 |
Mechanical Properties of Alloy Steel WP5 Pipe Bend
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| A234 WP5 | 415 - 585 | ≥205 | ≥20 |
Alloy Steel WP5 Pipe Bend Available Types :
| Alloy Steel WP5 Pipe Bend Supplier | Alloy Steel WP5 Buttweld Bend |
| Alloy Steel WP5 Mandrel Bends | Alloy Steel WP5 Long Radius Bend |
| Alloy Steel A234 WP5 Piggable Bend Manufacturer | Alloy Steel WP5 Hot Induction Bend |
| ASTM A234 WP5 Seamless Pipe Bend Suppliers | ANSI WP5 Welded Pipe Bend |
| Chrome Moly A234 WP5 U Pipe Bend Dealer | Alloy Steel A234 WP5 J Pipe Bend Exporter |
| Alloy WP5 Mitered Pipe Bend Stockholder | Steel WP5 3D Pipe Bend Distributors |
| Chrome Moly Alloy Steel WP5 5D Pipe Bend | A234 WP5 10D Pipe Bend Manufacturer |
| A234 WP5 Alloy Steel 2.5D Pipe Bend | WP5 Alloy Steel 22D Pipe Bend |
| Alloy Steel 5Cr-1/2Mo Customized Pipe Bend | Chrome Moly Alloy A234 WP5 Bend |
| ANSI B16.9 Alloy Steel WP5 12D Pipe Bending | Alloy Steel WP5 High Pressure Bending Stockist |
| ASTM A234 Alloy WP5 180 Degree Pipe Bend | ASME SA234 Alloy Steel WP5 DIN Pipe Bend |
| Chrome Moly Alloy Steel WP5 EN Pipe Bend | WP5 Alloy Steel ASME Pipe Bend |
| A234 WP5 Small Size Pipe Bending | ASME SA234M Alloy WP5 Pipe Bend Elbow |
| Steel WP5 90 Degree Pipe Bend Exporter | A234 WP5 160 Deg Pipe Bend |
Alloy Steel WP5 Pipe Bend Price List
- Alloy Steel WP5 10D pipe bend, Alloy Steel WP5 bended steel pipe, Alloy Steel WP5 bended steel tube
FOB Price in India : US $50-10000 / Piece - Alloy Steel WP5 3D hot bender for pipe tube bending
FOB Price in India : US $50-10000 / Piece - best price Of Hot Alloy Steel WP5 Pipe Bends Elbow
FOB Price in India : US $10-1000 / Piece - Alloy Steel WP5 Long radius hot bend pipes
FOB Price in India : US $0.06-0.39 / Ton - Alloy Steel WP5 pipe bend
FOB Price in India : US $0.2-526 / Piece
Alloy Steel WP5 Pipe Bend Application
- Industrial Boilers
- Power Plants
- Nuclear Plants
- Oil & Gas Industry
- Refineries
- Ship Building
- Heat Exchangers
- Condensers
- Paper & Pulp
- Marine Applications
- Nuclear Power
- Fossil Fuel Power Plants
